Nexus

Nexus panels are a resin edged panel with multiple grads of impact resistance. Typically used for wall applications these panels can be built with many custom options.

Product Image

Product Image

Product Image

Nexus

Nexus panels are a resin edged panel with multiple grads of impact resistance. Typically used for wall applications these panels can be built with many custom options.

University of Toronto

Hotel X

Saint Francis College

overview

Nexus Panels are a custom manufactured wall panel system. Nexus can be built in standard sizes such as 4’ X 6’ or 4’ X 8’ or be manufactured in any custom size catering to your design needs.

View Video

View 360 Panorama (VR)

Features

Available in 3 different finishes
Multiple thickness’s available 1” (25mm), 2” (50mm) , 3” (76mm), 4” (101mm)
4 Different impact resistant layers available

Benefits

Highly customizable to your design
High sound absorption
Excellent resistance to impact in abusive environments

Feature & Benefits Image

Finish Options

Finish Option Image

download pdf

Coated Finish

Smooth monolithic finish in our standard AURA White or any custom colour!

Finish Option Image

download pdf

Finto Finish

High resolution printed wood grain fabric available in 7 standard prints or custom.

Finish Option Image

download pdf

Fabric

Many fabrics, vinyls and felt available from Guilford of Maine, FilzFelt, Knoll, Design Tex, Maharam, Carnegie, Omnova and many more.

Finish Option Image

download pdf

Core Options

With Sky Acoustics, you have the flexibility to choose the core that best aligns with your project’s goals, whether it’s for unmatched customizability, sustainability, or both.

Available Impact Layers

Layer Image

Standard

Panel Composition

Medium Density Fiberglass Core 6-7 PCF
Choice of finish

Recommended Use:

Areas where panels are not likely to receive abuse or impact.

Layer Image

High Impact

Panel Composition

Medium Density Fiberglass Core 6-7 PCF
High Density Fiberglass Facer (HDF)
Choice of finish

Recommended Use:

Added protection to panels
Areas where slight abuse or impact may occur.
Tackability Adds 1/8” (3mm)

Layer Image

High Impact Ultimate

Panel Composition

Medium Density Fiberglass Core 6-7 PCF
High Density 8crim
Choice of finish

Recommended Use:

Gymnasium

Layer Image

Nova

Panel Composition

Medium Density Fiberglass Core 6-7 PCF
Perforated Co-polymer
Choice of finish

Recommended Use:

Gymnasium

General Data

Noice reduction Coefficient (NRC ) as tested to ASTM C423 in our 1” meets a 0.90 NRC

Noice reduction Coefficient (NRC ) as tested to ASTM C423 in our 2” meets a 1.05 NRC

Noice reduction Coefficient (NRC ) as testd to ASTM C423 in our 3” + meets a 1.30 NRC

Fire Performace as testd to ASTM E84 meets a class “A” fire rating w/a Flame spread index of 0 and a smoke Development index of 10

Our Standard “AURA White” in the coating system has been tested to a ASTM E1477-9a and has a rating of 90% light Reflectance

Edge Details Available

Shape Image

Square

Shape Image

Radius

Shape Image

Bevel

Shape Image

Miter

Shape Image

Tegular

Product Details

technical data

Mounting Systems

leed data

cleaning

details

installation

NEXUS-Data-sheet-2024

Download Here

HOOK-LOOP-MAGNET-WALL-MOUNT

Locked

Download Here

IMPAILING-CLIP-Datasheet-2024

Locked

Download Here

WALL-BRACKET-CONTINUOUS-WALL-TRACK-Datasheet-2024

Locked

Download Here

EDS-NEXUS-Environmental-Data-Sheet

Locked

Download Here

COATED-Cleaning-Instructions-1

Download Here

FABRIC-Cleaning-Instructions-1

Download Here

LEGNO-Cleaning-instructions-1

Download Here

LOHA-Cleaning-Instructions-1

Download Here

Wall-Panel-Details-ZClip_Impaling

Locked

Download Here

No files are available for this category at the moment. Please check back later.

Nexus Featured In
